WWII Springfield Armory M1 Garand U.S. .30-06 Semi Automatic Rifle 1941 C&R
SOLD FOR: $1750
WOA#: WY230110DC004
Our Assessment: The U.S. Rifle, Caliber .30, M1 is known affectionately as “the Garand” after its inventor, John Garand. The rifle would become the first standard-issue semi-automatic infantry rifle in the world. While some countries entered the war with limited issued semi-automatic rifles or developed such rifles during the war, America was the only nation to enter with its Army issuing autoloading rifles on a large scale. General Patton famously referred to the rifle as “the greatest battle implement ever devised”. Millions were produced during WWII and hundreds of thousands afterward, seeing use through the Korean War and into the Vietnam War. Interestingly, while many other weapons and military items would see production contracts sent out to otherwise non-related companies, during WWII production remained with Springfield Armory and Winchester. It was only after the war that production would be contracted out to another gunmaker, Harrington & Richardson, as well as the agricultural equipment maker, International Harvester.
This original Springfield Armory M1 Garand was originally made in 1941 and retains all Springfield original parts. The barrel was arsenaled in 1965 likely for use in South Korea and Vietnam. This M1 Garand has a strong bore and will be putting .30-06 downrange for a long time to come. Please see our specs below, photos, and good luck on your bid!
Make: Springfield Armory
Model: M1 Garand
Serial Number: 211431
Year of Manufacture: 1941. Barrel Date: June, 1965
Caliber: .30-06 Springfield
Action Type: Semi Auto, En Bloc Clip Fed
Markings: There is no import mark.
Receiver: “U.S. RIFLE / CAL. .30 M1 / SPRINGFIELD / ARMORY / 211431”.
Trigger Group: “D26290-8-SA”- A Springfield part (page 90 of Joe Poyer’s M1 GARAND 1936 to 1957, 6th Edition).
Hammer: “046008-5 SA”– A Springfield part (page 98).
Safety: “C46015-65A” – A Springfield part.
Follower & Slide: “11” – Original factory part Springfield.
Receiver Leg: “D 28291-3 SA J8B 3 ” – Correct for the Springfield serial number. This is a September, Heatlot Original USGI Springfield Armory “J 8 B” coded receiver.
Op Rod: “D35382 9 SA” – A Springfield
Barrel: “SA 6535448 6 65 BU19”, “P”, “M” with a Defense “Eagle” acceptance stamp, and other inspection stamps – A Springfield part (pages 63 – 65).
Bolt:“D28287 19SA B-19”- A Springfield Part
The stock and sights are described below.
Barrel Length: Approximately 24 Inches
Sights / Optics: The front sight is a blade set between two protective wings. The rear sight is a fully adjustable aperture sight set between two protective wings. The windage knob is marked “LEFT arrow” twice and “NHC”. The elevation knob is marked from “2-12”.
Stock Configuration & Condition: The bottom of the traditional pistol grip is marked “21” in paint. The wood stock has a traditional pistol grip, metal nose caps, stacking loop, three sling loops, and a metal buttplate with hinged door for storage in the butt. The buttplate shows scrapes, scratches and thinning. The wood shows numerous scrapes, scratches and compression marks. The wood has been oiled. The LOP measures 13 inches from the front of the trigger to the back of the buttplate. The stock rates in about Very Good overall condition.
Type of Finish: Parkerized
Finish Originality: Arsenal Refinished
Bore Condition: The grooves are semi bright and the rifling is deep. There is fouling and light intermittent erosion in the grooves. The fouling should clean up some. The bore shows an M.E. of 1. The throat shows a T.E. of 2.
Overall Condition: This rifle retains about 85% of its metal finish as refinished. The bottom metal shows scrapes & surface erosion. The gas tube shows scrapes & scratches. The metal shows other handling marks. The receiver and bolt show light operational wear. The markings are deep. Overall, this rifle rates in about Very Good condition as arsenal refinished.
Mechanics: The action functions correctly. We did not fire this rifle. As with all used firearms, a thorough cleaning may be necessary to meet your maintenance requirements.
Box, Paperwork & Accessories: S.Korean Canvas Sling with Korean Hangul.
