WWII Springfield CMP Rack Grade M1 Garand M1D Clone Criterion Barrel 1944
SOLD FOR: $1,200.00
LSB#: WY240908DL022
Make: Springfield Armory
Model: M1 Garand CMP Rack Grade converted to M1D clone.
Serial Number: 3263519
Year of Manufacture: Receiver November 1944, Barrel Date 10-2016, sold by the CMP 2022.
Caliber: .30-06 Springfield
Action Type: Semi Automatic rifle, En Block Clip Fed
Markings:
Receiver: “U.S. RIFLE / CAL. .30 M1 / SPRINGFIELD / ARMORY / 3263519”.
Trigger Group: “D28290-14-SA”.
Hammer: “C46008-7 SA”.
Follower: Unmarked
Receiver Leg: “A 16 D 28291 35 5”
Op Rod: “6535382 SA”
Bolt: “D28287-12SA / W98”.
Safety: “SA-11”
Barrel: “FA .30-06 CB 6535448-C 1-10 10/16 5F” This is a Fulton Armory Barrel By Criterion.
Windage knob is marked “LEFT” twice with two arrows and “DRC”.
Elevation Knob is marked 2-12 in increments of two and “NHC”.
Stock: The front of the grip is marked with circle “P” acceptance stamp. The stock bevel just behind the action is marked with a flaming bomb stamp. The left side in front of the wrist is marked “RIA” in a box with an illegible two letter code underneath the RIA. This is an Arsenal rebuild code for Rock Island Arsenal.
Barrel Length: Approximately 24” Inches.
Sights / Optics: The front sight is a blade set between two protective wings. The rear sight is a fully adjustable aperture set between protective wings. The windage knob is marked “LEFT arrow” twice and “DRC”. The elevation knob is marked “2-12”.
Stock Configuration & Condition: The three piece stock has a semi-pistol grip, metal nose caps, two sling loops, stacking loop and a metal buttplate with a hinged door for storage. The length of pull is 13” from the front of the trigger to the back of the buttplate. The wood on the stock shows compressions, lines, and scratches throughout. The belly in front of the bottom metal shows a large chip/scratch, there are chips missing from the toe of the heel, there is a notable gouge in the left flank behind the sling ring, and a chip in the left side at the seam back from the sling ring. There are no visible cracks in the wood. The forward section of the handguard has been refinished or is an Arsenal replacement part. The nose cap and metal buttplate have lost their finish, turned brown and show surface rust. Overall the stock is in Good condition considering the age and the finish originality.
Type of Finish: Parkerized, Shuffs Parkerizing did the barrel installation and refurb/repark
Finish Originality: Original and refinished.
Bore Condition: The bore is bright with sharp rifling. There is no detectable pitting or erosion in the bore. According to our gauges the muzzle reads at 9.0 with a throat of 0. In this writer’s opinion the bore rates 10/10.
Overall Condition: This rifle retains about 90% of its metal finish. The receiver, cylinder, cylinder lock, and cylinder plug have been refinished. The barrel and trigger group are replacement parts. The elevation knob has turned brown with patina. The bolt and action show rub wear on the friction surfaces. There is some discoloration on the rear sight plate. The markings are well defined and the screw heads are sharp. Overall this rifle is in Good+ to Very Good condition for a CMP Rack Grade rifle.
Mechanics: The action functions correctly. We have not fired this rifle. As with all previously owned firearms, a thorough cleaning may be necessary to meet your maintenance standards.
Box, Paperwork & Accessories: This rifle includes a foam padded cardboard box, Yellow chamber flag, En-bloc clip, certificate of authenticity, thank you card, manual, and info sheet.
Our Assessment: This Springfield M1 Garand with a 1944 receiver reflects the U.S. military’s robust firearm production during World War II. Springfield Armory, the primary manufacturer of the M1 Garand, produced millions of these semi-automatic rifles, which were a mainstay of American infantry during the war. A receiver from 1944 places this rifle’s origins in the heart of wartime production, likely intended for use in the European or Pacific Theaters. The rifle was later sold as a CMP Rack Grade Rifle in 2022.
To restore functionality and enhance its accuracy, the rifle’s original barrel was replaced with a Criterion barrel. Criterion barrels are known for their high-quality craftsmanship and are a popular choice for Garand restorations, offering modern precision while maintaining compatibility with the rifle’s original design. Additionally, the installation of a barrel block scope mount transforms this rifle into an M1D clone. The M1D configuration, developed during and after World War II, featured a scope mounted to the side of the barrel, designed for use by designated marksmen. While this rifle is not an original M1D, the modifications closely replicate its appearance and functionality.
In conclusion this rifle represents a fascinating mix of history and modern customization. As a CMP Rack Grade rifle, it has a legacy of military service. M1D clones are popular among collectors and enthusiasts for their historical significance and practical shooting capability. While not an original sniper rifle, this Springfield M1 Garand serves as a tribute to the original M1D design, blending wartime heritage with modern craftsmanship in a package that is meant to be shot, not simply boxed up and admired. To better understand this M1 please see our high quality photos via the link and best of luck with your bidding!!!-R.L.
