US WWII Springfield M1 M-1 Garand .30-06 Semi Automatic Rifle, MFD 1943 C&R

Sold For: $1,625

LSB#: 201018CA35

Make: Springfield Armory

Model: M1 Garand

Serial Number: 1634124

Year of Manufacture: June, 1943 (page 185 of Joe Poyer’s M1 GARAND 1936 to 1957, 6th Edition). June, 1943 Barrel Date

Caliber: .30-06 Springfield

Action Type: Semi Auto, En Bloc Clip Fed

Markings: There is no visible import mark.
Receiver: “U.S. RIFLE / CAL. .30 M1 / SPRINGFIELD / ARMORY / 1634124”
Trigger Group: “D28290-12-SA”- A Springfield part (page 89 of Joe Poyer’s M1 GARAND 1936 to 1957, 6th Edition).
Hammer: “C46008-9 SA” – A Springfield part (page 98).
Safety: Unmarked
Follower: Unmarked (page 83).
Receiver Leg: “0 3 3 B”, diamond, “J” and “D 28291 27”.
Op Rod: “D365382 9 SA” – A Springfield part (page 71).
Barrel: “2-S-A-6-43″ – A wartime Springfield part (page 63 – 64).
Bolt: “D28287-12SA / RE5B” – A Springfield part (page 53).

The stock and sights are described below.

Barrel Length: Approximately 24 Inches

Sights / Optics: The front sight is a blade set between two protective wings. The rear sight is a fully adjustable aperture sight set between two protective wings. The windage knob is marked “LEFT arrow” twice. The elevation knob is marked “BATTLE / RANGE”, “UP” and “DOWN” with arrows.

Stock Configuration & Condition: The left of the stock is marked “O.G.” in box cartouche (Ogden Arsenal).
The hardwood stock has a pistol grip, metal nose caps, a stacking loop, two sling loops, and a metal buttplate with hinged door for storage in the butt. The buttplate is worn to white and shows light scraping. The wood shows nicks, dings, bruises, scrapes, scratches and scuffs scattered throughout. There are a couple of deep dings on the right of the forend below and in front of the op-rod. There are no chips or cracks. The LOP measures 13 inches from the front of the trigger to the back of the buttplate. The stock rates in about Very Good overall condition as refinished.

Type of Finish: Parkerized

Finish Originality: Refinished

Bore Condition: The bore is mostly bright with sharp rifling. There is infrequent minor erosion in the bore. The bore shows an M.E. of about 2.25. The throat shows a T.E. of about 3.5.

Overall Condition: This rifle retains about 87% of its metal finish as refinished. The finish is thinning at most edges. There is some scattered finish wear, most notable toward the muzzle. There are some scattered light scuffs and scratches. The action shows operational wear. The markings are clear. Overall, this rifle is in about Very Good condition.

Mechanics: The action functions correctly. We did not fire this rifle. As with all used firearms, a thorough cleaning may be necessary to meet your maintenance requirements.

Box, Paperwork & Accessories: The rifle comes with a green canvas sling. It shows scrapes on the metal end tab and minor wear in the canvas. It is in about Very Good-Fine condition. There is a cleaning rod set in a green canvas case stored in the buttstock.

Our Assessment: This Springfield Armory M1 Garand was made back in 1943. The metal and wood have been refinished so the rifle looks good for its age. This M1 Garand is a 77 year old service rifle that can still do a lot of work out at the range. It should add nicely to your collection.
